| Model | LB 150 |
| Type | Jaw Crusher |
| Jaw Inlet Dimensions | 150 * 100 mm |
| Feed Size | Up to 150 * 100 mm |
| Output Particle Size | 0 - 5 mm (Adjustable) |
| Body Structure | Reinforced Steel Construction |
| Jaws | 16-18% Mn / Cr Alloyed Cast Steel |
| Motor Power | 2.2 kW, 380 V (220 V Optional) |
| Capacity | 50 - 150 kg / Hour (Varies by output size) |
| Noise Emission Level | Max. 85 dB |
| Electrical System | Motor Protection Thermal Switch |
DESCRIPTION: This machine is utilized in mineral processing laboratories for crushing ore samples up to a maximum diameter of 100 mm into various particle sizes. The distance between the jaws can be adjusted via the adjustment bolts located at the rear of the machine. For instance, crushing can be performed within a minimum range of 0-5 mm. Sample specimens can also be obtained by increasing the gap between the jaws (e.g., 0-10 / 0-15 / 0-20 / 0-30 mm, etc.).
AREAS OF USE: It is employed as a crusher in the mining, chemical, fertilizer, glass, and recycling industries. Special production in compliance with food standards is also available upon request.
SPARE PARTS: LB 150 Jaw Crushers are projected in CAD-based programs, and all components forming the machine are processed on CNC machines. Spare parts are continuously maintained in our stocks.
| Model | LB 280 |
| Rotor Nominal Dimensions | 240 * 500 mm Ø |
| Inlet Size | Max 150 mm (For limestone and similar hardness) |
| Output Particle Size | 0 - 5 mm (Adjustable particle size) |
| Capacity | 100 - 300 kg / Hour (Varies by material and output size) |
| Body Structure | Steel Construction |
| Blow Bars and Liners | 16-18% Mn / Cr Alloyed Cast Steel |
| Motor Power | 15 kW, 380 V, 50 Hz |
| Electrical System | Soft-starter via Electrical Panel |
| Model | LB 100 |
| Type | Jaw Crusher |
| Jaw Inlet Dimensions | 100 * 100 mm |
| Feed Size | Up to 100 x 100 mm |
| Output Particle Size | 0 - 5 mm (Adjustable) |
| Body Structure | Reinforced Steel Construction |
| Jaws | 16-18% Mn / Cr Alloyed Cast Steel |
| Motor Power | 2.2 kW, 380 V (220 V Optional) |
| Capacity | 50 - 150 kg / Hour |
| Noise Emission | Max. 85 dB |
| Electrical System | Motor Protection Thermal Switch |
| Model | LB 250 |
| Feed Size | -10 mm |
| Output Particle Size | Min. 0 - 3 mm (Adjustable) |
| Rollers | Cr Alloyed Cast Steel (Heat-treated for hardening) |
| Capacity | 10 - 50 kg / Hour (Varies by output size) |
| Motor Power | 1.5 kW / 380 V (Equipped with thermal protection switch) |
| Noise Emission Level | Max. 85 dB |
| Model | LB 260 |
| Crushing & Grinding Chamber (D/L) | 160 mm / 240 mm |
| Motor Power | 2.2 kW / 1400 rpm |
| Feed / Output Size | Min. > -1 mm (Exchangeable bottom sieves for various sizes) |
| Dimensions (WLH) | 500 * 700 * 900 mm |
| Weight | 130 kg |
