| Model | LB 260 |
| Crushing & Grinding Chamber (D/L) | 160 mm / 240 mm |
| Motor Power | 2.2 kW / 1400 rpm |
| Feed / Output Size | Min. > -1 mm (Exchangeable bottom sieves for various sizes) |
| Dimensions (WLH) | 500 * 700 * 900 mm |
| Weight | 130 kg |
INTENDED USE: This type of crusher is utilized to reduce materials that cannot be crushed by impact—such as wood, wood products, fiberglass, plastic-based products, and electronic circuit boards—to a specific particle size through a cutting action.
AREAS OF USE: It is extensively used in industrial factory laboratories, R&D and analysis centers, and engineering faculty laboratories for sample preparation.
OPERATIONAL DETAILS: The LB 260 Blade Crusher is mounted on a sturdy steel platform. The fed material is shredded (cut) between the blades on the rotor and the grinding wall. Various particle sizes can be obtained by utilizing exchangeable sieves. The processed material is collected in a sliding drawer located at the bottom of the platform. The platform can be fixed to the floor or made mobile by attaching wheels to the pre-drilled mounting holes.
Technical Build & Blade Features
Robust Construction: The outer housings are manufactured from high-quality steel construction for maximum durability.
High-Performance Rotor: Features replaceable, heat-treated, and precision-ground blades mounted on the rotor for superior cutting efficiency.
Reversible Blade Design: The cutting blades are designed to be reversible (double-sided), allowing for extended service life and cost-effectiveness.
Stock Availability: All components and spare parts are projected via CAD software and manufactured on CNC machines, with continuous stock availability.
| Model | LB 280 |
| Rotor Nominal Dimensions | 240 * 500 mm Ø |
| Inlet Size | Max 150 mm (For limestone and similar hardness) |
| Output Particle Size | 0 - 5 mm (Adjustable particle size) |
| Capacity | 100 - 300 kg / Hour (Varies by material and output size) |
| Body Structure | Steel Construction |
| Blow Bars and Liners | 16-18% Mn / Cr Alloyed Cast Steel |
| Motor Power | 15 kW, 380 V, 50 Hz |
| Electrical System | Soft-starter via Electrical Panel |
| Model | LB 100 |
| Type | Jaw Crusher |
| Jaw Inlet Dimensions | 100 * 100 mm |
| Feed Size | Up to 100 x 100 mm |
| Output Particle Size | 0 - 5 mm (Adjustable) |
| Body Structure | Reinforced Steel Construction |
| Jaws | 16-18% Mn / Cr Alloyed Cast Steel |
| Motor Power | 2.2 kW, 380 V (220 V Optional) |
| Capacity | 50 - 150 kg / Hour |
| Noise Emission | Max. 85 dB |
| Electrical System | Motor Protection Thermal Switch |
| Model | LB 150 |
| Type | Jaw Crusher |
| Jaw Inlet Dimensions | 150 * 100 mm |
| Feed Size | Up to 150 * 100 mm |
| Output Particle Size | 0 - 5 mm (Adjustable) |
| Body Structure | Reinforced Steel Construction |
| Jaws | 16-18% Mn / Cr Alloyed Cast Steel |
| Motor Power | 2.2 kW, 380 V (220 V Optional) |
| Capacity | 50 - 150 kg / Hour (Varies by output size) |
| Noise Emission Level | Max. 85 dB |
| Electrical System | Motor Protection Thermal Switch |
| Model | LB 250 |
| Feed Size | -10 mm |
| Output Particle Size | Min. 0 - 3 mm (Adjustable) |
| Rollers | Cr Alloyed Cast Steel (Heat-treated for hardening) |
| Capacity | 10 - 50 kg / Hour (Varies by output size) |
| Motor Power | 1.5 kW / 380 V (Equipped with thermal protection switch) |
| Noise Emission Level | Max. 85 dB |
